Making and maintaining timber bolts requires certain woodworking knowledge and skills. Below I will explain in detail how to make and maintain timber bolts:
1. Making timber bolts
Tools and materials required:
Hardwood (such as beech, maple, oak, etc., with a tight and hard texture), lathe or hand file, saw, thread cutter die (external thread die) or thread cutter, drill press (for making matching internal thread holes), sandpaper or scraper, wood glue (such as for enhancing thread strength)
Steps of making:
1. Choose wood
Choose dry, crack-free, and uniformly textured hardwood. The moisture content of the wood should be low (about 10%) to avoid shrinkage and deformation in the future.
2. Turning and shaping
Use a lathe to process the wood into a round bar with the required diameter of the bolt (such as M12 is 12mm), and turn out the nut part.
3. Cut threads
Use a woodworking thread die or a special thread cutting tool to cut threads along the axial direction.
If there are no special tools, metal thread molds can also be used, but they need to be operated slowly to prevent tearing the wood.
You can apply some wax or oil on the surface of the rod before processing to reduce friction.
4. Making nuts
Use the same wood as the bolt, drill holes and use an internal thread cutter or a resin-reinforced matching nut structure.
You can apply woodworking glue to strengthen the connection.
5. Sanding and processing
Smooth the surface with sandpaper to avoid burrs.
You can wax, apply wood oil or varnish to prevent moisture and cracking.
2. Maintenance of timber bolts
1. Moisture and crack prevention
Place in a dry and ventilated place, avoid high humidity or strong direct sunlight.
You can apply wood wax oil or linseed oil regularly to keep the wood moist.
2. Prevent deformation
Do not use it for a long time in a high humidity environment.
Timber bolts are not suitable for carrying very high structural loads and violent twisting should be avoided.
3. Anti-wear
You can apply a small amount of paraffin or talcum powder on the thread surface before use to reduce wear.
If the thread is loose after long-term use, you can apply wood glue inside the thread and use it after it dries.
4. Inspection and maintenance
Regularly check the bolts for cracks or peeling, and replace them in time if problems are found.
The use environment should be as stable as possible to avoid sudden changes in temperature.
If you want to make more precise timber bolts for structural parts, it is recommended to use a dedicated woodworking thread tool and strictly control the drying and processing accuracy of the wood. You can also refer to the spiral joint method of traditional woodworking mortise and tenon structure, such as the "spiral nail tenon" of traditional Japanese woodworking.
